Commercial Casefeeder

https://rollsizer.com/shop/csfr-comm-commercial-casefeeder-413 https://rollsizer.com/web/image/product.template/413/image_1920?unique=fe61767

The Rollsizer.com Casefeeder is supplied with a universal pistol calibre shellplate as standard and is supplied with a power adaptor to suit your either AUS, USA or European plugs. The Commercial casefeeder comprises of the Standard casefeeder with the Hopper extension which is required to be bolted to the standard casefeeder (it takes about 15 minutes) to remove the clear polycarbonate panel and bolt on the hopper. You will need a 5mm allen key and a 10mm spanner (not supplied).

 We strongly recommend the Commercial casefeeder for the Higher volume reloader and commercial processors.

The casefeeder is a totally new design, manufactured from high end engineered materials and components, it is robust and flexible for position and angles to suit most applications. The angle is adjusted using a simple cam lock device on the base.

The Commercial Casefeeder is a stand alone machine designed to be able to be fitted to most presses and will hold around 4,500 x 9x19 cases. The casefeeder can supply cases over 10,000 cases per hour.

The Casefeeder is supplied with a connector hose and twist lock to connect to the casefeeder as standard. We recomend the casefeeder position be trialed a number of times BEFORE the connecting hose is cut. It is critical that the customer test the casefeeder position and adjust the position of the casefeeder to suit their requirements. The connecting hose MUST be disconnected from the drop chute before any adjustments of the casefeeder angle is done. It is expected some work will be required to connect the end of the casefeeder hose to your press. The hose connection will work fine with rollsizer.com machines but we cannot design solutions for every press or combination.

We STRONGLY recomend customers join the Official Rollsizer.com Facebook group as we will be uploading customers solutions for press adaptors and solutions as soon as they become available. We will also be able to supply technical advise on how to best operate the casefeeder.

The Casefeeder has the following features.

1. Throughput to over 10,000 cases per hour for 9x19, 38S/SC, 40S&W and 45ACP. other cases such as revolver and magnum cases will have slightly different rates.
2. Universal shellplate to cover most pistol cases**
3. Variable speed to suit your application / demand.
4. Contactless chute fill sensor (no mechanical switch in the drop chute to fail)
5. Provision for a Rare Earth magnet to be placed just below sensor to pick up steel cases. This will hold up to 40mm diameter magnets and does not effect the sensor operation.
6. Auto detection jam detection with automatic reverse / forward function.
7. Momentary Reverse button.
8. Case count up to 9,999 cases. This is able to be turned on / off.
9. Programmable count stop up to 9,999 cases. This is able to be turned on / off.
10. Overload protection.
11. Adjustable casefeeder level angle. This allows the hopper to be lowered to around 45 degrees to clear out cases. The connection hose MUST be disconnected before changing the casefeeder angle.
12. Adjustable mounting post that can be securely locked in position to suit customers requirements. The post will accept up to 36mm diameter posts and up to 25mm (1") square posts.
13. Supplied with clear Polycarbonate side panel to allow you to determine the case level in the feeder (standard casefeeder). This is removed and replaced with the hopper for the commercial arrangement.
14. Casefeeder and Hopper extension are supplied with a hinged lid to reduce noise and dust (important when processing soiled cases).
15. Waste slots in the casefeeder tub to allow loose primers and minor rocks and dirt to clear the hopper and not get lifted into the discharge chute.
16. Will fit directly on the Rollsizer.com Commercial Rollsizer and is perfect for high volume applications using the post supplied with the rollsizer.
17. Supplied with a high quality wall mounted AC / DC power suply (100VAC up to 270VAC ok).

The reloading market has never had a cost effective casefeeder capable of keeping up with our commercial Rollsizers (or even our Decappers). The existing reloader casefeeders are simply are not designed for reliable high volume processing. Problems such as waterfall spillages cannot occur. Our casefeeders are designed for 100% duty operation and have been designed for competitors and processors alike.

Your time is valuable, running your equipment fast especially for rollsizing and decapping saves time.

*The casefeeder is supplied with a standard shellplate and will process the following cases at high rates (generally at or above 10,000cases per hour). 380ACP, 9x19, 38 Super / Supercomp, 357SIG/40S&W, 45ACP.

Slower rates will apply to 38SPL, 357 Mag, 44SPL, 44Mag.

The casefeeder will be able to process rifle cases at slower rates we tested these tofor  reliably feed up to 3,000 cases per hour. We are currently testing a high volume rifle plate and drop chute. This is expected to be released 2nd Quarter 2026. The preliminary test results are good and we expect 5,500 >6,500 cases per hour (to be confirmed).

The Operation and Maintenance manuals are under development will be available via the Support tab below as soon as they are available. This will be regularly updated and expanded as we identify improvements so we recomend you look for updates regularly when you receive your machine.
